Power BI Tools: A Comprehensive Guide

  • November 15, 2023
  • 3995
  • 96
Author Images

Meet the Author : Mr. Bharani Kumar

Bharani Kumar Depuru is a well known IT personality from Hyderabad. He is the Founder and Director of Innodatatics Pvt Ltd and 360DigiTMG. Bharani Kumar is an IIT and ISB alumni with more than 18+ years of experience, he held prominent positions in the IT elites like HSBC, ITC Infotech, Infosys, and Deloitte. He is a prevalent IT consultant specializing in Industrial Revolution 4.0 implementation, Data Analytics practice setup, Artificial Intelligence, Big Data Analytics, Industrial IoT, Business Intelligence and Business Management. Bharani Kumar is also the chief trainer at 360DigiTMG with more than Ten years of experience and has been making the IT transition journey easy for his students. 360DigiTMG is at the forefront of delivering quality education, thereby bridging the gap between academia and industry.

Read More >

In the fast-paced world of data-driven decision-making, having the right tools at your disposal is paramount. One such powerhouse of corporate information is Microsoft's Power BI. This suite of tools is designed to help businesses transform their data into actionable insights, making it an indispensable asset for any organization.

A Comprehensive Guide to Ribbon Charts, Waterfall Charts, Area Charts, and Clustered Bar Charts in Power BI. In this blog, we will explore various chart types and how they can help you gain maximum insights from your data. Whether you're a business professional or a data analyst in this manual, you'll learn how to use these charts effectively to analyze and visualize your data.

Learn the core concepts of Data Science Course video on YouTube:

What is PowerBI

Microsoft created a set of analytics tools called Power BI that allow users to connect to a variety of local and cloud-based data sources, transform the data, and visualize it for better decision-making.

Key Components:

  • Power BI Desktop: A desktop app for creating reports and dashboards, equipped with tools for data preparation, modeling, and visualization.
  • Power BI Service: A cloud-based platform for publishing and sharing reports and dashboards, offering features like scheduled data refreshes and collaboration tools.
  • Power BI Mobile: A mobile app for accessing and interacting with Power BI reports and dashboards on the go, ensuring data connectivity anytime, anywhere.
  • Gateway for : Acts as a bridge to connect Power BI with on-premises data sources, ensuring secure data refreshes for up-to-date reports.
  • Power BI Embedded: A Microsoft service enabling developers to seamlessly integrate Power BI visuals and reports into their own applications for user interaction.

Power Bi Tools

Unleashing the Potential of Power BI Tools: A Comprehensive Guide

Power BI Tools, on the other hand, refer to the individual software components and features within the Power BI suite, including:

  • Power Query: This is a data connectivity and data preparation tool that allows users to connect to various data sources, transform and clean the data, and load it into Power BI for analysis.
  • Power Pivot: With the help of this data modeling tool, users may define calculated columns and measurements, link various data tables together, and carry out more complicated data modeling operations.
  • DAX (Data Analysis Expressions): This is the formula language used in Power BI for creating calculated columns, measures, and other advanced calculations.
  • Visualizations: Power BI provides a variety of visualization tools, like as charts, graphs, maps, and custom graphics, to assist users in clearly and persuasively presenting data.
  • Q&A (Natural Language Query): This feature allows users to ask queries and receive immediate answers in natural language visual responses, making it easier in order to examine and analyze data for non-technical people.

Understanding Ribbon Charts

In essence, ribbon charts show the change in a variable over time. They do this in a way that is more visually appealing than a standard line chart. The ribbons are stacked on top of each other, and their width and color change as the data changes.

Ribbon charts are useful for showing how multiple sets of data change over time. They are often used to show how different aspects of a business change in relation to each other. For example, you might use a ribbon chart to show how sales, expenses, and profits change over a period of time.

Creating Ribbon Charts in Power BI is a straightforward process that can add a dynamic visual element to your reports. Follow these steps:

Unleashing the Potential of Power BI Tools: A Comprehensive Guide
  • Open Power BI Desktop: Launch the Power BI Desktop application on your computer.
  • Connect to Data Source:
    • Click on the "Home" tab in the Power BI Desktop.
    • Select the data source you want to connect to (e.g., Excel, SQL Server, etc.).
  • Load Data:Once connected, you'll see a preview of your data. Select the tables or queries you want to use and click "Load" to import the data into Power BI.
  • Open a New Report Page:On the left-hand panel, click on the "Report" icon to open a new report page.
  • Insert a Ribbon Chart:
    • In the Visualizations pane (usually on the right side of the screen), find the Ribbon Chart icon (it looks like a series of horizontal bars).
    • Click on the Ribbon Chart icon to add it to the report canvas.
    Unleashing the Potential of Power BI Tools: A Comprehensive Guide
  • Add Fields to the Chart: In the Fields pane (usually on the right side of the screen), drag and drop the fields you want to use for the Ribbon Chart into the appropriate areas (e.g., Axis, Legend, and Values).The following picture displays the chosen fields in the Data pane and the modified fields in the Visualizations pane for the ribbon chart. Unleashing the Potential of Power BI Tools: A Comprehensive Guide The new ribbon chart shows the rank for This Year Sales for every month: Unleashing the Potential of Power BI Tools: A Comprehensive Guide
  • Format and Customize: With the Ribbon Chart selected, you can use the Formatting options in the Visualizations pane to customize the appearance, colors, and other aspects of the chart.
  • Interact with the Chart: You can interact with the Ribbon Chart by clicking on different elements. Power BI will update the chart dynamically based on your selections.
  • Save and Publish: Once you're satisfied with the Ribbon Chart, save your Power BI file.
  • Publish to Power BI Service (Optional): If you wish to share the report online, click the icon in the toolbar that shows the desired fields, then follow the instructions to submit it to the Power BI service.

Become a Data Science with a single program. Go through 360DigiTMG's Data Science course in Bangalore! Enroll today!

Understanding Waterfall chart

It's an effective visualization for showcasing positive and negative variances against target values, offering insights into the contributions of each component to the overall result. In Power BI, creating a Waterfall Chart is a valuable skill for financial analysis and performance tracking. Let's proceed to the steps for creating one in Power BI.

To create the waterfall chart, we must have actual values and targeted numbers over time. Below is the monthly target vs actual no’s.

Unleashing the Potential of Power BI Tools: A Comprehensive Guide Unleashing the Potential of Power BI Tools: A Comprehensive GuideUnleashing the Potential of Power BI Tools: A Comprehensive GuideUnleashing the Potential of Power BI Tools: A Comprehensive Guide
  • Prepare Data: You need to prepare data as above that it should have actual and target values.
  • Import Data into Power BI:
    • Save your data in an Excel workbook.
    • Open Power BI and click "Get Data" > "Excel" to import the file.
  • Navigate to Data: In the "Data" view, locate your imported table.
  • Create a New Column: Under "Modeling," click "New Column." Unleashing the Potential of Power BI Tools: A Comprehensive Guide It will ask you to name a new column. Unleashing the Potential of Power BI Tools: A Comprehensive Guide
  • Name the Column and Enter DAX Formula: Name it "Variance." and Use the formula: "Actual - Target." Unleashing the Potential of Power BI Tools: A Comprehensive Guide After the formula, press the “Enter” key. It will create a new column for our existing table. Unleashing the Potential of Power BI Tools: A Comprehensive Guide
  • Insert a Blank Column Chart: Go to the "Report" tab, click "Blank" under "Visualizations."
  • Add Fields: Drag "Financial Month" to "Axis" and "Variance" to "Values."
  • Select Waterfall Chart:
    click on the column chart, then choose "Waterfall Chart" from the visualization options. Unleashing the Potential of Power BI Tools: A Comprehensive Guide The column chart may automatically convert to the waterfall chart. Unleashing the Potential of Power BI Tools: A Comprehensive Guide Sort by Month:Click on the three dots at the top-right of the chart, go to "Sort by," and choose "Month." Unleashing the Potential of Power BI Tools: A Comprehensive Guide The chart is sorted as below based on Month Unleashing the Potential of Power BI Tools: A Comprehensive Guide
  • Format the Chart: Adjust font sizes, data labels, and sentiment colors as needed. Add a title under the "Title" formatting category.
  • Finalize the Waterfall Chart: Now, you have a Waterfall Chart showcasing variances against targets over time.

Data Science is a promising career option. Enroll in Data Science traning in Hyderabad offered by 360DigiTMG to become a successful Data Scientist.

Understanding Area Charts

An Area Chart is a visual representation of quantitative data trends over a continuous range. It displays data points connected by lines, with the area below the line filled. This chart is effective for comparing and analyzing multiple data series, providing insights into the magnitude and accumulation of values.

Unleashing the Potential of Power BI Tools: A Comprehensive Guide

steps for creating a basic Area Chart

Unleashing the Potential of Power BI Tools: A Comprehensive Guide
  • Open Power BI Desktop: Launch Power BI Desktop on your computer.
  • Connect to Data:
    • Click on the "Home" tab and select your data source (e.g., Excel, SQL Server, etc.).
    • Load the data you want to work with.
  • Create a New Report Page: On the left-hand panel, click on the "Report" icon to open a new report page.
  • Insert an Area Chart: In the Visualizations pane, find the Area Chart icon (it looks like a line chart with a shaded area below it).
  • Add Data Fields:
    • Drag and drop the relevant fields into the appropriate areas.
    • For example, you might use a date field for the Axis, and numerical fields for the Values.
  • Customize and Format:
    • Use the Formatting options in the Visualizations pane to customize the appearance, colors, and other aspects of the chart.
    • Adjust the color of the area and line, if desired.
  • Interact with the Chart: Click on elements in the chart to see specific values and how they contribute to the total.
  • Save the File
  • Optional: Publish to Power BI Service

Understanding Clustered Bar Charts

A clustered bar chart is a data visualization that displays multiple bars grouped together for each category or data point. It's used to compare values across different categories or sub-groups. Each cluster represents a distinct category, and the height of the bars within the cluster represents the values associated with that category. This chart type is effective for visualizing and comparing data sets with multiple variables or sub-categories. It provides a clear visual representation of the relationships between different data points, making it a valuable tool for data analysis and decision-making in fields such as business, finance, and statistics.

Unleashing the Potential of Power BI Tools: A Comprehensive Guide

Steps for Creating the Clustered Bar Chart

Unleashing the Potential of Power BI Tools: A Comprehensive Guide
  • Open Power BI Desktop: Launch Power BI Desktop on your computer.
  • Connect to Data: Click on the "Home" tab and select your data source (e.g., Excel, SQL Server, etc.) and load the data you want to work
  • Create a New Report Page: On the left-hand panel, click on the "Report" icon to open a new report page.
  • Insert a Clustered Bar Chart: In the Visualizations pane, find the Clustered Bar Chart icon (it looks like a set of vertical bars) and click on it to add it to the report canvas.
  • Add Data Fields:
    • Drag and drop the relevant fields into the appropriate areas.
    • For example, you might use a category field for the Axis, and numerical fields for the Values.
  • Customize and Format: Use the Formatting options in the Visualizations pane to customize the appearance, colors, and other aspects of the chart.
  • Interact with the Chart: Click on elements in the chart to see specific values and compare data points.
  • Save the File.
  • Optional: Publish to Power BI Service

Pros of PowerBI Tools

  • Data Integration: Power BI seamlessly integrates with various data sources, allowing for easy data import and transformation.
  • Interactive Visualizations: A variety of fully customisable visualizations are available to make interactive and interesting reports.
  • Real-Time Data Updates: Power BI can be set up to provide real-time or scheduled data refreshes, ensuring reports are always up-to-date.
  • Mobile Accessibility:Users can access reports and dashboards on mobile devices, enabling on-the-go data analysis.
  • Natural Language Querying: The Q&A tool in Power BI enables users to ask questions in straightforward language and get visual answers.
  • Integration with Microsoft Ecosystem: It seamlessly integrates with other Microsoft tools like Excel, SharePoint, and Teams.
  • Data Security and Governance: Power BI offers robust security features, ensuring data privacy and compliance with industry regulations.
  • AI and Machine Learning Capabilities: Power BI incorporates AI and machine learning for advanced data analysis, forecasting, and sentiment analysis.
  • Cost-Effectiveness: Power BI is affordable for enterprises of all sizes, with several pricing tiers and a free version available.
  • Coordination and sharing: Collaborative capabilities make it easier for team members to work together on data projects, while reports and dashboards can be quickly shared with other team members.

360DigiTMG offers the best Data Science course in Chennai to start a career in Data Science. Enroll now

Conclusion

As you embark on your data-driven journey, remember that Power BI tools are your trusted companions. Feel free to immerse yourself in the world of insights, where creativity knows no bounds. Comment, connect, and collaborate with the vibrant Power BI community; your questions and contributions are invaluable. Let your data tell its story, and watch as Power BI transforms it into actionable intelligence. So, dive in with confidence, explore the possibilities, and let Power BI be the catalyst for your success in the realm of business analytics.
